MD9000VET Veterinary 12.1 Inch Color TFT Patient Monitor, 7 Channels ECG
- MD9000VET Veterinary 12.1 Inch Color TFT Patient Monitor
- Features professional veterinary software
- Monitors ECG, SpO2, NIBP, RESP, and 2-TEMP
- Compact and portable design with built-in rechargeable lithium battery
- Displays ECG waveforms of 7-leads on the same screen
- SKU
- OD-00431
- Brand
- Meditech
- Availability
- In stock
- ✓ Warranty included
- ✓ Worldwide shipping
MD9000VET Veterinary 12.1 Inch Color TFT Patient Monitor
Professional-grade veterinary patient monitoring system with 7-channel ECG display, multi-parameter tracking, and portable design. Ideal for small animal, large animal, and exotic veterinary surgical and critical care environments.
Clinical overview
The MD9000VET is a comprehensive veterinary patient monitoring system designed for anesthesia, critical care, and surgical applications across small animal, large animal, and exotic species. The 12.1-inch high-resolution color TFT display provides clear visualization of multiple parameters simultaneously, enabling clinicians to make rapid, informed decisions during procedures.
With simultaneous monitoring of ECG (7-channel), SpO2, NIBP, respiratory rate, and dual temperature inputs, the system delivers real-time hemodynamic and oxygenation data. The built-in rechargeable lithium battery ensures portability and continuous operation for over 180 minutes, making it suitable for mobile veterinary clinics, field operations, and remote surgical settings. Advanced trend analysis, comprehensive alarm management, and full-disclosure waveform review support evidence-based patient care.
Key features & surgeon benefits
7-Channel ECG Waveform Display
- Simultaneous 7-lead ECG display on single screen
- 5-lead or 3-lead mode selection for flexible electrode placement
- Adjustable waveform and data color schemes for optimal visibility
- 72-hour graphic and tabular trend data storage
Multi-Parameter Real-Time Tracking
- ECG with arrhythmia and ST-segment analysis
- SpO2, NIBP (oscillometric), respiratory rate, dual temperature
- Species-specific NIBP ranges: big animal, small animal, very small animal modes
- 480 alarm event recall with 8–32 seconds waveform history
Lightweight, Battery-Powered Design
- Compact 310 × 140 × 263 mm footprint; 3.8 kg weight
- Rechargeable 7.4V lithium battery: >180 minutes operating time
- Ideal for mobile clinics, field anesthesia, and remote procedures
- Optional thermal printer for real-time waveform documentation
Modular Optional Modules
- Invasive Blood Pressure (IBP) with 8 selectable labels
- Capnography (CO2) module for respiratory monitoring
- Masimo SpO2 module for enhanced oxygen saturation accuracy
- Wall mounts and trolley systems for fixed or mobile installation
Technical specifications
| Indications | Veterinary anesthesia monitoring, critical care, surgical procedures (small animal, large animal, exotic species) |
|---|---|
| Display | 12.1 inch color TFT (Sharp Japan); 7 waveforms maximum |
| ECG Modes | 5-lead (I, II, III, avR, avL, avF, V) or 3-lead (I, II, III); gain 2.5–20 mm/mV; HR range 30–350 bpm (species-dependent) |
| NIBP Method | Oscillometric; manual, auto, STAT modes; big animal, small animal, very small animal pressure ranges |
| SpO2 | Pulse oximetry with multi-site Y-type cable; optional Masimo module |
| Temperature | 2 channels; range 0–50°C; resolution 0.1°C; accuracy ±0.1°C |
| Respiratory Rate | Monitored and displayed in real-time |
| IBP (Optional) | 2 channels; labels ART, PA, CVP, RAP, LAP, ICP, P1, P2; range 0–300 mmHg (ART); accuracy ±2% or 1 mmHg |
| Data Storage | 72-hour short-term trend (1-second resolution); 72-hour long-term trend (1-minute resolution); 480 alarm events; 400+ NIBP measurements; 72-hour full-disclosure waveform review |
| Battery | Rechargeable 3.7 A/Hr 7.4V lithium; operating time >180 minutes at full charge |
| Dimensions | 310 × 140 × 263 mm |
| Weight | 3.8 kg |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| ECG Cable | 5-lead configuration | 1 |
| ECG Alligator Clips | Metal, for electrode attachment | 5 |
| SpO2 Cable | Multi-site Y-type | 1 |
| Temperature Probe | Pointy type | 1 |
| NIBP Cuff | 26–35 cm (5 per bag) | 1 |
| NIBP Tube | 150 cm length | 1 |
| Ground Cable | Patient safety grounding | 1 |
| Power Cable | AC mains connection | 1 |
| Cleaning Cloth | Display and housing maintenance | 1 |
Optional accessories & modules
| Category | Item |
|---|---|
| ECG | 3-lead cable; additional alligator clips |
| SpO2 | External cable; multi-site Y-type variants |
| NIBP Cuffs | 8–14 cm; 3–20 cm; 18–26 cm; 26–35 cm; 29–38 cm; 32–42 cm; 35–44 cm; 42–50 cm (all 5 per bag); disposable animal cuffs |
| Capnography | EtCO2 module; CO2 sample line; nasal tube; water-trap column; airway adapter |
| IBP | IBP adapter (2-IBP); reusable interface cable; disposable transducers |
| Recording | Thermal printer; paper rolls (48 mm width; 25/50 mm/s speed) |
| Installation | Wall mounts (3 models); trolley systems (5 models) |
Get in touch for pricing & availability
Contact our sales team to discuss the MD9000VET system, customisation options, and delivery timelines for your veterinary facility or mobile clinic.
Email: [email protected]
Available on request
Configuration, paperwork & clinical fit
The full spec + documentation pack for this device ships ahead of purchase on request. A sales engineer responds within one business day.
Configuration sheet
Specifications, accessories & clinical fit
Sizes and dimensions, material and finish, compatible instruments and screw references, what ships in the set, lead time and warranty — all in one specification sheet, sent within one business day.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Need configuration help, certificates, or volume pricing?
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
