- Portable 2D B/W Ultrasound scanner with advanced transducer technology
- 10 inch CRT Screen with clear image quality
- Multiple imaging modes including B, B/B, 4B, B+M, and M
- Comes with a standard multi-frequency convex probe and options for additional probes, printer, battery, and trolley
Advanced portable 2D B/W ultrasound scanner with 10-inch CRT display, digital beam forming, and multiple imaging modes. Engineered for clinical flexibility with optional multi-frequency probe configurations and expandable connectivity for diagnostic imaging across diverse clinical settings.
The Dolphi® Pro is a clinically robust portable B/W ultrasound scanner designed for versatile diagnostic imaging across multiple specialties. Featuring a high-resolution 10-inch SVGA display with 256 grey-scale levels and advanced digital beam forming technology, the system delivers clear, real-time imaging with minimal dead zone (≤3mm) and excellent lateral and axial resolution. The patented innovative design incorporates real-time dynamic aperture and four-section electronic focusing to optimise image quality across varying depths, making it suitable for obstetric, gynaecological, abdominal, vascular, and soft tissue assessment.
The scanner supports multiple imaging modes (B, B/B, 4B, B+M, M) and offers flexible magnification options (×0.8 to ×2.0) with depth-hoist display capability. Integrated calculation functions include distance, perimeter, area, heart rate, and obstetric parameters (BPD, GS, CRL, FL, AC) with anticipated delivery date estimation. The system's expandable architecture accommodates optional multi-frequency probes (3.5MHz to 7.5MHz), B/W laser printer, battery backup, trolley, and ultrasonic workstation integration, enabling seamless workflow adaptation to institutional requirements.
| Indications | General diagnostic ultrasound imaging, obstetrics, gynaecology, abdominal, vascular, soft tissue assessment |
|---|---|
| Probe (standard) | 80-element array, R60 geometry, 3.5MHz multi-frequency convex |
| Scanning depth | ≥180mm |
| Lateral resolution | ≤2mm (depth ≤80mm); ≤3mm (80<depth ≤130mm) |
| Axial resolution | ≤1mm (depth ≤80mm); ≤2mm (80<depth ≤130mm) |
| Dead zone | ≤3mm |
| Geometry position precision | Lateral ≤5%; axial ≤5% |
| Display modes | B, B/B, 4B, B+M, M |
| Monitor | 10-inch SVGA high-resolution (256 grey-scale levels) |
| Magnification | ×0.8, ×1.0, ×1.2, ×1.5, ×1.8, ×2.0 (depth hoist display) |
| Dynamic range | 64–96dB adjustable |
| Focusing | Four sections of dynamic electronic focusing |
| Cine loop memory | 256 frames |
| Image storage | 128 images permanent storage |
| Frequency conversion | 2.5MHz, 3.0MHz, 3.5MHz, 4.0MHz, 6.5MHz, 7MHz (with optional probes) |
| Video output | 2× SVGA, 2× PAL; 1× USB (optional) |
| Power supply | AC 110V/220V±22V 50/60Hz; input ≤300VA |
| Operating hours | ≥8 hours continuous (with optional battery) |
| Net weight | 7kg |
| Gross weight | 10kg |
| Packing size | 480×380×410mm |
| Warranty | 2 Year Manufacturer Warranty |
| Item | Description | Qty |
|---|---|---|
| Multi-frequency convex probe | 80-element array, 3.5MHz standard configuration | 1 |
| Power cable | AC mains connection | 1 |
| Cleaning cloth | Microfibre probe cleaning cloth | 1 |
| Accessory | Description |
|---|---|
| 7.5MHz high-frequency linear array probe | For superficial and high-resolution imaging |
| 6.5MHz intra-cavity (trans-vaginal) probe | For gynaecological and obstetric assessment |
| 7.5MHz rectal probe | For rectal and pelvic imaging |
| 3.5MHz micro-convex probe | For intercostal and confined-space imaging |
| B/W laser printer | Hard-copy image output |
| Footswitch | Hands-free image capture control |
| Battery backup | Portable operation without mains power |
| Trolley | Mobile cart for bedside deployment |
| Ultrasonic workstation | Integration with PACS and image management systems |
Contact our sales team to discuss system configuration, probe options, and delivery timelines. We provide comprehensive technical support and clinical training to ensure optimal integration into your diagnostic workflow.
Available on request
The full spec + documentation pack for this device ships ahead of purchase on request. A sales engineer responds within one business day.
Configuration sheet
Sizes and dimensions, material and finish, compatible instruments and screw references, what ships in the set, lead time and warranty — all in one specification sheet, sent within one business day.
Documents & downloads
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
