DHS & DCS Plate Instrument Set
- Complete set of instruments for DHS & DCS plating procedures
- Includes various sizes of tap, drill bits, and screwdrivers for versatile use
- Features depth gauge and lag screw depth measuring device for accuracy
- Comes in a convenient aluminum box for easy storage and transport
- SKU
- 4200-05
- Brand
- Orthopromed
- Availability
- In stock
- ✓ Warranty included
- ✓ Worldwide shipping
DHS & DCS Plate Instrument Set
Complete surgical instrument set for dynamic hip screw and dynamic condylar screw plating procedures. Includes comprehensive taps, drill bits, depth gauges, and specialized guides for accurate fracture fixation in proximal femur and distal femur applications.
Clinical overview
The DHS & DCS Plate Instrument Set is a comprehensive surgical solution designed for trauma surgeons performing dynamic hip screw and dynamic condylar screw fixation. This complete kit includes all essential instruments required for accurate drilling, tapping, measuring, and screw placement in proximal and distal femur fracture fixation. The set combines precision engineering with ergonomic design to support efficient, reproducible surgical technique.
Each instrument is manufactured to exacting standards and supplied in a protective aluminium storage box for convenient transport and sterilisation. The set accommodates both standard and specialized surgical approaches, with dedicated angle guides for DHS (135°) and DCS (95°) applications, ensuring optimal implant positioning and patient outcomes.
Key features & surgeon benefits
Complete Surgical Workflow
- 22 precision instruments in single kit
- Covers drilling, tapping, measuring, and insertion
- Dual angle guides for DHS and DCS procedures
Precision Measurement & Guidance
- Depth gauge (0–100mm) for accurate screw length
- Lag screw depth measuring device
- Neutral and load drill guides for consistent positioning
Optimised Surgical Time
- T-handle quick coupling for rapid instrument changes
- Dual impactors (large and small) for versatile applications
- Colour-coded wrenches for intuitive instrument selection
Long-term Value
- Stainless steel construction for corrosion resistance
- Protective aluminium box for safe transport
- 2-year manufacturer warranty and lifetime support
Technical specifications
| Indications | Proximal femur fractures (DHS), distal femur fractures (DCS) |
|---|---|
| Sizes / range | Cortical tap 4.5mm, cancellous taps 6.5mm & 12mm, drill bits Φ4.5 & Φ3.2 (150mm), K-wire Φ2.5 (225mm) |
| Material | Stainless steel instruments, aluminium storage box |
| Sterilisation | Steam sterilisable (individual instruments) |
| Packaging | Protective aluminium box with foam insert |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| 1 | T-handle Quick Coupling | 1 |
| 2 | Tap Cortical 4.5mm | 1 |
| 3 | Double Drill Sleeve (Φ4.5/Φ6.5) | 1 |
| 4 | Double Drill Sleeve (Φ4.5/Φ3.2) | 1 |
| 5 | Neutral and Load Drill Guide Φ2.5 | 1 |
| 6 | Tap Cancellous 6.5mm | 1 |
| 7 | Drill Bit Φ4.5×150mm | 2 |
| 8 | Drill Bit Φ3.2×150mm | 2 |
| 9 | Lag Screw Depth Measuring Device | 1 |
| 10 | Tap Cancellous 12mm | 1 |
| 11 | Threaded K-wire Φ2.5×225mm | 3 |
| 12 | DHS/DCS Impactor Large | 1 |
| 13 | Depth Gauge (0–100mm) | 1 |
| 14 | DHS/DCS Impactor Small | 1 |
| 15 | DHS/DCS Wrench, Purple Sleeve | 1 |
| 16 | DHS/DCS Wrench, Golden Sleeve | 1 |
| 17 | Screwdriver Hexagonal 3.5mm | 1 |
| 18 | DCS Angle Guide 95 Degree | 1 |
| 19 | DHS Angle Guide 135 Degree | 1 |
| 20 | DHS Reamer | 1 |
| 21 | DCS Reamer | 1 |
| 22 | Aluminium Box | 1 |
