BJ1407B Acetabulum reaming drill (System 1400)
– Dual function acetabulum reaming drill for joint surgery
– Autoclavable with imported motor for low noise, high torque, and long service life
– Customizable interfaces for different shafts and reamers for quick and stable tool connecting
– Output power ≥75w, speed 0-280 r.p.m, torque 6.5 Nm, and voltage 9.6V
£1,390.00
Guaranteed Safe Checkout
Features & Compatibility
BJ1407B Acetabulum Reaming Drill (System 1400)
Dual-function acetabulum reaming drill engineered for joint surgery with fully autoclavable design, imported motor delivering low noise and high torque, and customizable interfaces for seamless integration with existing surgical systems.
Clinical overview
The BJ1407B is a dual-function acetabulum reaming drill designed specifically for joint surgery applications. With its ergonomic design and fully autoclavable construction, the handpiece meets the highest standards for sterile surgical environments. The imported motor delivers consistent performance with low noise output and high torque characteristics, ensuring reliable operation throughout extended surgical procedures.
Customizable interface options allow seamless integration with different shaft and reamer configurations, enabling quick and stable tool connections without compromising surgical precision. The device operates at variable speeds up to 280 rpm with a maximum torque of 6.5 Nm, providing surgeons with the control and power necessary for controlled acetabulum reaming in hip arthroplasty and revision procedures.
Key features & surgeon benefits
Fully Autoclavable Construction
- Complete handpiece sterilizable at 135°C (improved type ≤155°C)
- Imported motor engineered for long service life
- Ergonomic design reduces surgeon fatigue during extended procedures
High Torque, Low Noise Operation
- Output power ≥75W with 6.5 Nm torque for controlled reaming
- Variable speed 0–280 rpm for precision control
- Noise level ≤40 dB for improved OR environment
Customizable Interface System
- Adaptable interfaces for different shaft and reamer configurations
- Quick and stable tool connecting without compromise to stability
- Compatible with existing surgical protocols and instruments
Advanced Battery Technology
- Environment-friendly nickel-metal hydride battery system
- 9.6V operation with extended runtime per charge
- Battery removed post-surgery to maximize lifespan
Technical specifications
| Indications | Acetabulum reaming in joint surgery |
|---|---|
| Output Power | ≥75W |
| Speed Range | 0–280 rpm |
| Torque | 6.5 Nm |
| Operating Voltage | 9.6V |
| Noise Level | ≤40 dB |
| Sterilisation | 135°C autoclavable (improved type ≤155°C at 1.6 MPa) |
| Material | Medical-grade stainless steel |
| Packaging | Handpiece, battery, charger, aseptic battery transfer ring, operating manual, guarantee card |
| Warranty | 1 Year Handpiece; 3 Months Battery & Consumables |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Handpiece | BJ1407B dual-function acetabulum reaming drill | 1 |
| Battery | Nickel-metal hydride rechargeable battery (9.6V) | 1 |
| Charger | Battery charging unit with power adapter | 1 |
| Aseptic Battery Transfer Ring | Sterile transfer device for battery management | 1 |
| Operating Manual | Comprehensive user and maintenance guide | 1 |
| Guarantee Card | Warranty documentation | 1 |
Get in touch for pricing & availability
Contact our sales team to discuss your surgical requirements, request a detailed quote, or arrange a product demonstration. We provide comprehensive technical support and can customize interface configurations to match your existing surgical systems.
